|fixed||boom||luff||mast||main window||rec mast||pro performance mast||top||battens||weight (kg)|
|3.7||141||340||340||x-ply||SX8 RDM||SX10 RDM||adjustable||4||2.7|
|4.0||144||363||340||x-ply||SX8 RDM||SX10 RDM||adjustable||4||2.8|
|4.2||152||371||370||x-ply||SX8 RDM||SX10 RDM||fixed||4||2.8|
|4.5||157||382||370||x-ply||SX8 RDM||SX10 RDM||fixed||4||2.9|
|4.7||161||393||370||x-ply||SX8 RDM||SX10 RDM||fixed||4||3.0|
|5.0||164||405||400||x-ply||SX8 RDM||SX10 RDM||fixed||5||3.1|
|5.3||170||415||400||x-ply||SX8 RDM||SX10 RDM||fixed||5||3.2|
|5.6||175||424||400||mono||SX8 RDM||SX10 RDM||fixed||5||3.3|
|5.9||176||442||430||mono||SX8 RDM||SX10 RDM||fixed||5||3.3|
|6.2||181||453||430||mono||SX8 RDM||SX10 RDM||fixed||5||3.5|
// Split Batten Lineup
The Evoq features a split batten lineup for ultimate handling throughout all sizes. The 3.7 to 4.7 feature a 4 batten panel layout, and from 5.0 to 6.2 a 5 batten panel layout. The main benefit is that we can design the sail with the exact needed distance between the battens needed to achieve the right feeling for draft and stability. The sail sizes are progressively designed in both construction and sail profile. The smaller sizes have less sail profile, and the larger ones offer more low-end grunt for getting going in marginal conditions.
1 // Vertical Kevlar Load Line
Kevlar load line from top to tack to control the central effort; increase the longevity of the material which ensures that the sail profile stays in position when strong gusts hit the sail.
2 // Kevlar Stretch Control Tendons
The Kevlar Stretch Control Tendons distribute the load throughout the surface of the sail from clew to luff. They control the breaking point for the twist, increase the wind range, and increase the longevity of the sail. An original Simmer Style feature that has been widely adopted by many other sail brands.
// New Scrim Material Q2-Ply
Inspired by our successful Team Edition project, we created a new scrim designed explicitly for our foot and clew panels for durability and impact resistance. We call it Q2-Ply. It is 20% lighter than 5 MIL X-Ply but as strong due to its specification with super thin 90-degree polyester threads layered on a 30-degree wide-spaced kevlar pattern.
// Lightweight Construction, Strength Were It’s Needed
We only use the most durable laminate scrims on the market. 100% polyester film with high stretch resilience thread reinforcement. The layers of film are bonded together with a UV resistance glue. We only use lighter scrims (less strong materials) in areas where the swing weight is reduced and where the loading is fairly low. Our focus is not to build the lightest sail weighing sail on a scale. But to build the lightest sail in terms of feeling without sacrificing durability. Our X-Ply / Q2-Ply / Q-Ply Scrims are made by the leading manufacturer, Dimension Polyant in the USA.
// Durable Clew Design
A sails clew is a high load area, therefor all Simmer Style sails features seven layers reinforcement plus the a overlapping six layers from the finger tendons. The finger tendons distributes the loads over a greater a larger area of the sailcloth surface, which increases the durability, as well as the direct handling of the sail. On our wave sails we also use a stainless steel O-Ring, secured with six layers of strong nylon webbing. Simmer quality defined.
// Percision Tapered Battens
The Precision Tapered Battens are custom designed for each sail size to push the sail profile forward and keep the draft locked in for stability. Our battens are built with plus 50 layers of glasfiber/carbon that is laminated under extreme pressure. Then each batten is CNC machined to the exact tapered.
